DPJ-1600Multi-slate Bridge-typed Stone Cutter

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1317237

• Place of Origin:

  China
• The machine has guiding mechanism for vertical movement.The Box of Principle Axis moves laterally along a double-V-shapped guiderails on the beam.It adopts imported transducer to process variablespeed control and the mainbeam could move forward and backward.With its resonable mechanism,high degree rigidity and steady performance,it is an ideal option for processing granite, marble,sheet and fixed shaped material.
  Technical data
  Name
  Unit
    DPJ-1800
  DPJ-2200

  Grossbeam Length
    mm
    6500
    7000

  Max saw disc dimater
     mm
    1800
    2200

    Max.dimensions
     mm
  36502200800

  365022001000

  Main motor power
    kw
    30    37
    30   37

  Gross power
    kw
    35.2    42.2
    35.2   42.2

  Outside dimensions
    mm
    400065005000
    400070005000

  Approximate weight
    kg
    8000
    8500
